BAUMALIGHT FGS952-T590

$36,713.00
sold out
Feller Buncher For Skid Steer - FGS952 The FGS952 Skidsteer Mounted Feller Buncher we designed features a 52” cutting disc that can take up to 20” trees. The blade is specially designed using high alloy steel allowing it to be thinner which results in less binding and is equipped with 18 Beaver cutting teeth. The frame design allows more visibility for the operator and high stress areas use AR400 steel for added strength. The grabber arms are equipped with a special valve that directs all hydraulic flow to the grabber cylinder for a much faster and more powerful hug on the tree. It has an electric-over-hydraulic system which operates efficiently on hydraulic flows as little as 25 gpm and is powered by a bent axis piston motor. Only one set of remote hydraulics is required to operate all functions if you have an AUX electrical connection. Model No FBS752 FGS952 FBXD752 Baumalight Connection Code - - A03 Mounting type Skidsteer Mounted Skidsteer Mounted Excavator Mounted Blade position Fixed Horizontal Blade Fixed Horizontal Blade 360° Slew drive Adaptor Universal Skidsteer Adaptor Universal Skidsteer Adaptor Bolt-on Adaptor Slew Drive PSI 4000 PSI 4000 PSI 4000 PSI Case drain Requires Case Drain - Critical Requires Case Drain - Critical Requires Case Drain - Critical Electrical Requirement Requires 12V Electric Requires 12V Electric Requires 12V Electric Electric AUX Four 12V positive switchable signals required Two 12V positive switchable signals required Six 12V positive switchable signals required Wire Supplied or not Wire Supplied to AUX Wire Supplied to AUX Wire NOT Supplied Hydraulic Hose and Couplers Hoses Included Couplers NOT Included Hoses Included & Couplers NOT Included Hoses & Couplers NOT Included Blade diameter 52" Diameter Blade 52" Diameter Blade 52" Diameter Blade Maximum cut 20" Max Cut 20" Max Cut 20" Max Cut Blade Material 3/4" Steel Blade 5/8" AR400 3/4" Steel Blade Cutt thickness 1 5/8" Cutt Thickness 1 5/8" Cutt Thickness 1 5/8" Cutt Thickness Number of edges per Tooth 4 Edges Per Tooth 4 Edges Per Tooth 4 Edges Per Tooth Number of teeth 18 Teeth 18 Teeth 18 Teeth Tooth part number B8000 Beaver Teeth B8000 Beaver Teeth B8000 Beaver Teeth Throat Opening at teeth Throat Opening at teeth: 36" 36" Throat Opening 36" Throat Opening Weight 2850 lbs 2250 lbs 4415 lbs
