BAUMALIGHT TRL630D-2 SPEED

$0.00
sold out
Engine Hp - 24.5 HP Displacement - 1.1 L Engine Type - Diesel Fuel tank size - 40L Engine Brand - Kubota Model - D1105 Drive type Hydrostatic Drive control - Joy stick Carriage -Tracks Travel Speed - 8.8 Km/h Ground weight (without weight kit) 4 lbs per sq. in Relief setting (psi) - 3,000 GPM under no load - 10.5 Hydraulic Reservoir Capacity 40 Litres Number of pumps - 3 Boom control - Joy stick Self Leveling no yes yes Pin Height - 76" Ground clearance - 6.5" Width (without bucket) 40" Length without bucket - 70" Tipping (lifting) front edge of bucket - 1,600 Same as above with extra weight - 1,730 Tipping (lifting) without any attachment - 3,190 Same as above with extra weight - 3,500 Weight (lbs) - 2,930 Weight with weight kit - 3,170 WRL58G TRL536D TRL620D TRL620Y TRL630D TRL630Y Tipping capacity with bucket 830 1670 ~1820 ~1820 1820 ~1820 Same as above with extra weight 1180 1890 ~2050 ~2050 2050 ~2050 Lifting capacity with bucket 730 1570 ~1720 ~1720 1720 ~1720 Same as above with extra weight 1080 1790 ~1950 ~1950 1950 ~1950 ISO rated operating capacity* 415 585 ~637 ~637 637 ~637 Same as above with extra weight 590 662 ~718 ~718 718 ~718 The ISO tipping load for a skid steer is often cited as 35% of its total tipping load, which is the maximum weight the machine can hold before it becomes unstable and tips over. This 35% value is used to determine the machine's Rated Operating Capacity (ROC), a safety guideline for how much weight the skid steer can safely lift in normal operating conditions. PLEASE SEE VIDEO IN SUPPORT SECTION UNDER TIPPING VIDEO
