Misting System Gyratory Atomizing Nozzle Hose Input 3/4" Utility / Garden Hose Minimum Water Volume 1/3 Gallon Per Minute Maximum Water Volume 20 Gallons Per Minute @ 120psi Minimum Water Pressure 40 psi Maximum Water Pressure 120 psi Droplet size 50-200 Microns Throw Distance Horizontal Up to 125 ft. in Neutral Wind Conditions Throw Distance Vertical Up to 50 ft. in Neutral Wind Conditions Warranty 10 Year Manufacturer Warranty Engine Warranty 3 Year Warranty Input Power KDW1003 Kohler Engine Input RPM Up to 3600 RPM Outlet Size 12” Oscillation Settings up to 270° Length with wheels and handle removed 88” Overall Length with Nozzle and tow handle 136” Width 55” Max Height with nozzle in upright position 54” Weight 975 lbs. Transmitter Hand held wireless transmitter (water resistant) with push button control (manual control option available)
